2013 Aspire
-
aspire4
http://www.academybmx.com/wp-content/uploads/2012/07/aspire41.jpg
-
aspire4
http://www.academybmx.com/wp-content/uploads/2012/07/aspire4.jpg
-
aspire1
http://www.academybmx.com/wp-content/uploads/2012/07/aspire12.jpg
-
aspire9
http://www.academybmx.com/wp-content/uploads/2012/07/aspire9.jpg
-
aspire3
http://www.academybmx.com/wp-content/uploads/2012/07/aspire31.jpg
-
aspire8
http://www.academybmx.com/wp-content/uploads/2012/07/aspire8.jpg
-
aspire11
http://www.academybmx.com/wp-content/uploads/2012/07/aspire11.jpg
-
aspire7
http://www.academybmx.com/wp-content/uploads/2012/07/aspire7.jpg
-
aspire10
http://www.academybmx.com/wp-content/uploads/2012/07/aspire10.jpg
-
aspire5
http://www.academybmx.com/wp-content/uploads/2012/07/aspire5.jpg
-
aspire2
http://www.academybmx.com/wp-content/uploads/2012/07/aspire21.jpg
-
aspire3
http://www.academybmx.com/wp-content/uploads/2012/07/aspire3.jpg
-
aspire1
http://www.academybmx.com/wp-content/uploads/2012/07/aspire1.jpg
-
aspire6
http://www.academybmx.com/wp-content/uploads/2012/07/aspire6.jpg
-
aspire2
http://www.academybmx.com/wp-content/uploads/2012/07/aspire2.jpg
Frame: Academy Aspire 3 Main Tube CrMo 20.4”TT, 13.5” rear, 75.0º HA, 71º ST, MID BB, Integrated Headset.
Forks: Academy Tapered legs with CrMo steer tube.
Handlebars: Academy 8.25″ rise 28″ wide CrMo
Grips: Academy Pro
Headset: Integrated
Stem: Academy Pro Alloy Front Load
Brakes (rear): 990 style.
Brake lever (right): Alloy.
Cables: Slick (rear).
Sprocket: Academy 25T.
Crankset: Academy 3pce CrMo Tubular 8 spline, 175mm.
Bottom Bracket: Sealed Mid 19mm.
Chain: KMC Z510.
Pedals: Wellgo Plastic.
Rims: Alloy Single Wall 36h.
Front Tyre: 2.3″ Steel Belted.
Rear Tyre: 2.0″ Steel Belted.
Spokes: Black steel.
Front Hub – Academy Alloy 10mm axle, 36 hole, loose ball.
Rear Hub – Academy Alloy Cassette, 36 hole, 14mm axle, fully sealed bearing w/9t driver.
Seat & Seatpost: Academy Mid Seat/Post Combo.
Weight: 10.8kgs
